GRAVEL
Brisa TI
Robust but light titanium frame with superior vibration damping
Titanium | Carbon
Frame and fork material
SRAM Force E1 AXS
Wireless drivetrain
from 9.2 kg
Bike weight
700x47c
Maximum tire width
product unavailable
The devil's in the details
Our paintjobs
Silver Breeze
Design: LOCA | Tadek Ciechanowski
Design
The typography was created by Tadek Ciechanowski – he is behind many of our earlier projects and also works in our home city of Wroclaw. The inspiration came from neon forms and the urban aesthetic of cyberpunk. Against the backdrop of satin, raw titanium, the polished logos work like neon itself – drawing the eye without disrupting the simplicity of the overall design.
Execution
After glass bead blasting, the frame takes on titanium's natural satin finish. The logos are polished so the surface of the details reflects light, contrasting with the semi-matte texture of the rest of the frame.
Prism Breeze
Design: LOCA | Tadek Ciechanowski
Design
The design was created by Wroclaw-based artist Tadek Ciechanowski, with whom we have already created many projects. Neon-inspired typography was transferred onto raw titanium and complemented with anodised logos. That makes the details easy to read without overpowering the material's natural character.
Execution
After glass bead blasting, the titanium frame is polished and the logos are anodised. That process gives them a vivid colour that contrasts with the satin surface. The finish stands out for its durability and resistance to mechanical damage.
LOCA.CSTM
Bring your vision
to life
Do you have your own bike design idea?
We'll help you make it a reality!
Create a bike
with us!
LOCA.CSTM is a close collaboration with our team. Whether your idea for a new project is fully fleshed out or you're just starting your journey – you decide the final design and configuration!
Specification
Frameset
Frame
Titanium 3AL-2.5V, BSA 68 threaded bottom bracket shell (from 1650 g), 12x142x1.0 axle (171.5 mm)
Finish
Frame in a natural finish, with graphics created through anodising and polishing. Increased resistance to mechanical damage.
Fork
Carbon, tapered (from 540 g), 12x100x1.5 axle (120 mm)
Sizes
S (43 cm) | M (46 cm) | L (49 cm) | XL (52 cm)
Drivetrain
Front derailleur
None | SRAM Force AXS E1, 2x12s
Rear derailleur
SRAM Force AXS E1 XPLR Carbon 1x13 (Full Mount) | SRAM Force AXS E1 Carbon 2x12
Cassette
SRAM XG-1371, 10–46T, 1x13 | SRAM XG-1270, 10–36T, 2x12
Crankset
SRAM Force 1x13 AXS E1 WIDE Carbon 42t | SRAM Force 2x12 AXS E1 Carbon 46/33t, 165 mm (S); 170 mm (M); 172.5 mm (L, XL)
Bottom bracket
SRAM DUB BSA
Chain
SRAM Force AXS E1 Flattop (purple)
Brakes
Shift/brake levers
SRAM Force AXS E1 Carbon
Calipers
SRAM Force AXS E1
Rotors
SRAM HS2 160 mm
Cockpit
Handlebar
Integrated carbon cockpit; 80x400 mm (S) | 90x420 mm (M, L) | 100x440 mm (XL)
Bar tape
ZIPP Service Course CX
Wheels
Wheels
ZIPP 303 XPLR S Carbon | Mavic Allroad 700
Tyres
Tufo Thundero HD 700x44C, reinforced casing to help prevent cuts, one of the fastest gravel tyres on the market
Extras
Seatpost
Carbon, 27.2 mm; 0 mm offset
Saddle
Selle Italia Novus Boost (245x145mm)
Pedals
Not included
Hanger
UDH / Full Mount compatible
Weight
From 9.2 kg
Max. load
130 kg (ZIPP 303 XPLR S Carbon) | 120 kg (Mavic Allroad 700)
Where the tarmac ends
Geometry
The geometry of our titanium frames lets you run tyres up to 47 mm wide. A tall stack and sliding dropouts let you change the bike's character – from a fast, agile gravel bike for mellow dirt roads,
to a bikepacking beast that can handle technical terrain even with a heavy load of luggage. Adjustable dropouts length lets you fine-tune the balance between agility and stability.
| Size | S | M | L | XL |
|---|---|---|---|---|
| A Seat tube c-t (mm) | 430 | 460 | 490 | 520 |
| B Effective TT (mm) | 530 | 543 | 559 | 575 |
| C Head tube (mm) | 120 | 130 | 150 | 170 |
| D Chainstay (mm) | 425 | 425 | 425 | 425 |
| E Head tube angle (°) | 70.7 | 71.2 | 71.2 | 71.7 |
| F Seat tube angle (°) | 73.7 | 73.2 | 73.2 | 72.7 |
| G Wheelbase (mm) | 1005 | 1009 | 1026 | 1031 |
| H BB drop (mm) | 78 | 78 | 78 | 78 |
| I Reach (mm) | 368 | 373 | 383 | 387 |
| J Stack (mm) | 554 | 565 | 583 | 605 |
Proven construction and
uncompromising quality
We build every bike according to a single principle: it must be good enough that we'd want to ride it ourselves. The frames undergo rigorous strength tests in accordance with the European ISO standard. This is complemented
by a multi-stage quality control process: upon receipt of the frames, after painting, and after assembly. Thanks to this, we are confident that the Brisa will withstand years of intensive riding on the most demanding routes.
The ultimate gravel bike
Brisa TI is built for long hours and long distances. Thoughtful geometry and numerous mounting points mean it performs just as well on fast gravel with light kit as it does on multi-day trips with a full load. Interchangeable dropouts let you adapt the bike to your needs, regardless of the drivetrain type.
Titanium
Practically indestructible, corrosion-resistant, superb at damping vibrations and noticeably lighter than steel – that is titanium. We chose it for Brisa because of its unique blend of qualities that no other bike material can match. The natural finish eliminates the problem of scratched paint. On climbs, Brisa feels responsive thanks to its high lateral stiffness, while staying comfortable on long rides and stable under luggage loads. Brisa's hand-laid welds stand out for their remarkable precision.
SRAM Force E1 AXS
Wireless levers mean a clean cockpit and precise shifting. Tight gear steps and a wide range give you an advantage on climbs and fast sections alike. HS2 rotors dissipate heat better and boost braking power by up to 7% – brake with confidence even in extreme conditions. The carbon crank and derailleur cage bring greater stiffness and lower weight, while the extra buttons on the levers let you control your navigation more easily while riding.
From 9.2 kg
Titanium offers an excellent strength-to-weight ratio. While it is clearly lighter than steel bikes, it matches them for durability and ride comfort.
700x47c
Clearance in line with modern standards opens up huge tyre options – letting you run the best gravel tyres on the market.
Key features
Zero cables.
Zero compromise.
Thanks to FSA ACR technology and wireless drivetrains, all cables are fully hidden inside the cockpit and frame.
The result? A clean, minimalist look, easy cleaning, and full compatibility with handlebar-mounted bags. No cable damage. No complex setups. No spacers.
Versatile as a Swiss Army knife
Thanks to its thoughtful details, our gravel bike is a fantastic companion for long journeys – numerous mounting points for bottle cages, a rack and mudguards open up the world of bikepacking and cycling adventures. The cherry on top is the sliding, interchangeable dropouts. They let you tailor both geometry and drivetrain type to your needs.
Ride fast. Ride comfortably.
Carefully selected components deliver reliability and comfort on every kilometre.
Drivetrain built
for any condition
We use advanced wireless SRAM AXS groupsets in most of our gravel builds. Why? Set it once and forget it. Flawless shifting no matter the conditions, massive gear range, long battery life, low weight, great stiffness and a clean look. What more could you ask for?
Wheels that carry you
From the legendary ZIPP 303 XPLR S carbon wheels, through boutique Dandy Horse builds, to bombproof Mavics – we rely only on proven solutions that we have been riding ourselves for years. Tyres are just as important. We chose the Czech Tufo Thundero HD – one of the fastest gravel tyres on the market, with a reinforced casing that stands up brilliantly to cuts.
